3 Lines/Trunks
Assigning Telephone Buttons
For single-line telephones, answering machines, fax machines, or any other
device connected to an 012, 016, or 008 OPT module:
The settings for SA buttons can be changed (see below); however, factory
settings should be adequate to meet most user needs, since SA buttons
can be used to make and receive both inside and outside calls.
Single-line telephones cannot have additional SA or SSA buttons.
However, single-line telephones connected through an 012, 016, or 008
OPT module can have SA buttons removed from them. Removing all but
one SA button from Single-line telephones will disable features such as
Transfer, Conference, and any other feature that requires more than one
SA button.
If you want the extension to receive outside calls on a specific line/trunk,
assign a personal line button; if you want the extensions to receive outside
calls on a line/trunk included in a pool, assign a Pool button. See System
Programming for instructions.
For adjuncts connected using an MFM, it is recommended that you change the
Button 2 assignment to SA Orig Only and remove the Button 3 assignment.
Planning Form Instructions
1. Using the guidelines above, select the types of buttons to assign to each
telephone.
2. Complete the Button Diagram page of each copy of Forms 4b, 4c, 4d, 4e,
and 4f.
a.
b.
NOTE:
The button diagrams for DLCs (Forms 5a and 5b) will be completed
later.
On buttons 1 through 27, indicate the types of System Access
buttons by circling SA for SA Voice, SA Ring, or SA Orig Only, and
writing Ring or Voice or SA Orig Only buttons and writing Shared SA,
Pool, or Personal line. Then do the following as appropriate:
For an SSA button, include the number of the extension with
the associated SA button (see Form 2a), and the button
number on that telephone.
For a Pool button, include the pool's extension number (see
Form 2c).
For a personal line button, include the telephone number and
record the line/trunk numbers (see Form 2c).
Indicate whether all but one SA button will be removed from
Single-line telephones on Form 4f.
Assign Loudspeaker Page buttons by selecting the button and
writing Page on it.
