3 Lines/Trunks
Assigning Lines/Trunks
2. For any voice/voice or voice/data entries in the Person or Location column of
Form 2a, indicate the type of extension jack pairs under the Extension Jack
Pair heading on Forms 4b and 5a by doing one of the following:
3. For any adjuncts connected to an MLX telephone using an MFM, fill in the
following user information from Form 2b, System Numbering: Digital
Adjuncts on Forms 4e and 5c in the Connected to MLX extension No.
space:
a.
b.
4. Identify the equipment at each extension (see the floor plan):
a.
b.
Check the Voice Announce to Busy (voice/voice) box and enter the
logical ID and extension number under the Even-numbered jack
heading.
Check the Simultaneous Voice and Data (voice/data) box and enter
the logical ID and extension number under the Even-numbered jack
heading.
Write the extension number in the Extension No. space.
Write the name of the person or the location of the equipment in the
Person or Location space.
Check the box that describes the telephone, console model, or type
of tip/ring equipment.
Check the box under Adjuncts that describes the adjuncts at the
extension. (Checking the Data terminal box is informational only.)
