Bezels; Figure 12. Intel ® Local Control Panel - Intel SR1625UR - Server System - 0 MB RAM Service Manual

Callout
K.
L.
M.
N.
O.

Bezels

The optional front bezels provide a snap-on design that allows for maximum airflow
through the server chassis. Three bezels are available. One fits a system that has the
standard control panel installed. The second bezel is used for a chassis with the other
®
Intel Local Control Panel. The third bezel is used for chassis with the mini control panel
installed. Each bezel provides a lock to secure the hard drive and optical drive area. For
instructions on installing either of the front bezels, see
page 40.
The order numbers for the bezels are:
•
ASR1550MINBEZ: Black bezel for use with the Mini control panel.
•
ASR1550BEZ: Black bezel for use with the standard control panel.
•
ASR1550LCDBEZ: Black bezel for use with the Intel
®
Intel Server System SR1625UR Service Guide
Feature
NIC 2 Activity LED Continuous green light indicates a link between the system and
the network to which it is connected.
NIC 1 Activity LED
Blinking green light indicates network activity.
Hard Disk Activity Random blinking green light indicates hard disk drive activity
LED (SAS or SATA).
No light indicates no hard disk drive activity.
Reset Button Reboots and initializes the system.
USB Port Allows you to attach a USB component to the front of the system.
Figure 12. Intel
Function
®
Local Control Panel
"Installing the Front Bezel" on
®
Local Control Panel.
23
