Figure 36. Lifting The Processor Socket Lever; Figure 37. Opening The Load Plate - Intel SR1625UR - Server System - 0 MB RAM Service Manual

7. Push the rear tab with your finger tip to bring the front end of the load plate open
slightly (see letter "A" in
8. Open the load plate (see letter "B" in
9. Remove the protective socket cover (see
Note: Do not touch the orientation posts on the socket; they are very sensitive and easily
damaged.
Note: Retain the protective socket cover for use when removing a processor that will not be
replaced.
®
Intel Server System SR1625UR Service Guide
B

Figure 36. Lifting the Processor Socket Lever

Figure 37).
A

Figure 37. Opening the Load Plate

A
AF002835
Figure 37).
B
AF002836
Figure 38).
53
