Figure 74. Removing Mini Control Panel Module From The Server System; Figure 75. Connecting The Control Panel Cables - Intel SR1625UR - Server System - 0 MB RAM Service Manual

1. Press the latch at the back of the mini control panel and push the control panel
forward to release it from the system (see letter "A" in
2. Slide the mini control panel out through the front of the server system (see letter
"B" in
3. Remove the filler panel or two right drive carriers (see letter "C" in

Figure 74. Removing Mini Control Panel Module from the Server System

4. Connect the USB and data cables to the replacement control panel (see letter "A" in
Figure
5. Feed the cables of the replacement control panel through the chassis opening (see
letter "B" in
6. Slide the replacement control panel into the server system (see letter "A" in
Figure
7. Connect the two cables to the USB and control panel connectors on the
as shown (see letter "B" in
®
Intel Server System SR1625UR Service Guide
Figure 74).
B
C
75)
Figure 75).

Figure 75. Connecting the Control Panel Cables

76) until it clicks into place.
Figure
Figure
Latch
A
AF002868
Data
Cable
USB
Cable
A
B
AF002951
76).
74).
Figure 74).
backplane
87
