1
Server System Contents and
References
There are two versions of the Intel
•
Intel
•
Intel
Unless noted otherwise, all references to the Intel
both product codes.

Server System Contents

The Intel
information about the server board, see Intel
Specification.
The contents of each server system are listed below.
®
Intel Server System SR1625UR Contents
Your Intel
•
Intel
•
One 650-W power supply, installed in the server system
•
Full-length and full-height PCI Express* riser card assembly, installed in the server
system
•
Processor air duct, installed in the server system
•
Two processor heatsinks, installed in the server system
•
Passive midplane, installed in the server system
•
Hot-swap SAS/SATA backplane, installed in the server system
•
Bridge board, installed in the server system
•
Mini control panel, installed in the server system
•
Six 2.5-inch hot-swap drive trays and drive filler blanks, installed in the server
system
•
A filler panel (for drive locations 6 and 7), installed in the server system
•
System fan assembly, including five 40X40X56-mm dual-rotor fans, installed in the
server system
®
Intel Server System SR1625UR Service Guide
®
Server System SR1625UR (Passive system)
®
Server System SR1625URSAS (Active system)
®
Server System SR1625UR ships with the Intel
®
Server System SR1625UR (passive system) ships with the following items:
®
Server Board S5520UR, installed in the server system
®
Server System SR1625UR:
®
Server System SR1625UR refer to
®
Server Board S5520UR Technical Product
®
Server Board S5520UR. For
1
