Server Chassis Features

Advanced Management Options

®
Intel Management Module
Two versions of the Intel
management features.
The Intel Management Module - Professional Edition contains a hardware mezzanine card that
plugs into the server board.
The Intel Management Module - Advanced Edition includes a hardware mezzanine card,
10/100 Mb NIC mezzanine card, and cables.
For installation instructions on installing either Intel Management Module, see the instructions
provided with the management module.
✏
NOTE
Some server boards may not support the Intel
your server board documentation to determine if this feature is compatible
with your server board.

Rack-Mounted Systems

Your Server Chassis SR2400 is designed to be mounted into a rack. The Intel SR2400 server
chassis can be mounted using one of two accessories; the first is a tool-less rail kit and the second is
a fixed rail kit. When installing the chassis into a rack, Intel recommends you install systems from
the bottom of the rack to the top. In other words, install the first system in the rack into the bottom
position of the rack, the second system in the second position from the bottom, and so on.
Instructions for installing your chassis into a rack are included in the rail kit.
The order numbers are as follows:
Tool-less Rail Kit: AXXHERAIL
Fixed Rail Kit: AXXBRACKETS
Cable Management Arm: AXXRACKCARM (requires the tool-less rail kit)

Front Bezels

The optional front bezels provide a snap-on design that allows for maximum airflow through the
server chassis. Two bezels are available. One fits a system that has the Standard Control Panel
installed. The other is used for a chassis with the other Intel Local Control Panel. Each bezel
provides a lock to secure the hard drive and floppy drive / CD-ROM / DVD-ROM drive area. For
instructions on installing either of the front bezels, see
The order numbers for the bezels are:
Black bezel for use with the Standard Control Panel: ADRBEZBLACK
Black bezel for use with the Intel
Intel® Server Chassis SR2400/SR2400DC User Guide
®
Management Module are available to provide additional server
®
Local Control Panel: ADRLCDBEZEL
®
Management Module. See
"Removing and Installing the Front Bezel".
11
