Bezels - Intel SR1630BC - Server System - 0 MB RAM Service Manual

LED Color
System Green
status (on
standby
power)
Amber
Off
Disk Green
Activity
Off

Bezels

The optional front bezel provides a snap-on design that allows for maximum airflow
through the server system. The bezel fits a system that has the standard control panel
installed (with or without a video port). The bezel provides a lock to secure the hard drive
and optical drive area. For instructions on installing the front bezel, see
Front Bezel".
The order number for the bezel is:
•
AHJBEZBLACK: Black bezel for use with the standard control panel.
16
Table 4. Control Panel LED Functions
State
On
Blink
On
Blink
Off
Random blink
Off
Description
Running / normal operation
System ready, but degraded
Critical or non-recoverable condition. Possible critical
power module failure, critical fan failure, voltage
(power supply), voltage and thermal fault.
Non-critical condition
POST / system stop. System not read.
HDD access
No hard disk activity
Intel® Server System SR1630BC Service Guide
"Installing the
