Back Panel Connectors

A.
C.
E.
®
Intel
Server System SR1625UR Service Guide
Serial Port A (RJ-45)
USB Ports 0 and 1
NIC 1 (10/100/1000 Mb)

Figure 14. Back Panel Connectors

B.
Video
D.
USB Ports 2 and 3
F.
NIC 2 (10/100/1000 Mb)
25
