Connector Pin-Out; Connection Layout; Connection Schematic - Advanced Navigation Certus OEM Reference Manual

Certus Reference Manual • Specifications
Parameter
Output Voltage High
Output Current
Active Antenna Supply Voltage
Antenna Supply Current
Table 17: Electrical Specifications

5.7 Connector Pin-out

The electrical connection to the Certus OEM is through Molex and JST connectors to board mounted
connectors.

5.7.1 Connection Layout

The following illustration shows the connection locations on the Certus OEM unit.
Ethernet 1PPS
Primary MMCX
Figure 9: Certus OEM Breakout Connector Locations

5.7.2 Connection Schematic

The following illustration shows the schematic of the breakout connections.
v2.4
Minimum
3 V
GNSS Antenna
4.5 V
GPIO Primary
CAN
Page 23
Typical
5V
Auxiliary
Secondary MMCX
Maximum
3.3 V
50 mA
4.6 V
200 mA
Power Input
2024-12-17
