Certus Reference Manual • Interfacing
GPVTG, GPRMC, GPHDT, PASHR, GPROT, GPHEV, GPGSV, PFECGPAtt, and PFECGPHve
tion :
at up to 50 Hz. The messages output and the output rate can be configured using the web UI or
Certus Manager. An example output is shown below.
$GPZDA,031644.460,07,05,2013,00,00*52
$GPGGA,031644.460,3352.3501851,S,15112.2355488,E,6,00,1.4,150
.0,M,0.0,M,,*7E
$GPVTG,089.19,T,089.19,M,000.00,N,000.00,K,E*27
$GPRMC,031644.460,A,3352.3501851,S,15112.2355488,E,0.0,89.2,0
70513,12.5,W,E*02
$GPHDT,89.2,T*06
$PASHR,031644.460,089.19,T,-00.01,-00.47,-00.00,,,,0,0*2E

9.6.1.42 ANPP Output

Type
:
GPIO Port
:
Auxiliary
:
:
Description

9.6.1.43 TSS1 Output

Type
:
GPIO Port
:
Auxiliary
:
:
Description

9.6.1.44 Simrad 1000 Output

Type
:
GPIO Port
:
Auxiliary
:
Description
:
v2.4
Serial Transmit
1
Transmit
This function outputs data in the ANPP format as specified in
Packet Protocol. This function is for ANPP peripheral devices only.
When this function is enabled, the GPIO and auxiliary ports function except for:
When setting the ANPP packet and message output rates, the changes only apply
l
to the port you are connected to. For example, you cannot change the primary port
or GPIO port packet and message rates when connected to the auxiliary port.
Serial Transmit
1
Transmit
This function outputs the TSS1 format at a user configurable rate of up to 50 Hz. The
output rate can be configured using the page in the web UI.
Serial Transmit
1
Transmit
This function outputs the Simrad 1000 format at a user configurable rate of up to 50 Hz.
The output rate can be configured using the
8.2.7.11 GPIO Output dialogue in the Certus Manager.
Page 137
10 Advanced Navigation
8.1.3.6 GPIO page in the web UI or the
2024-12-17
