rates for the same packet ID.

10.5.2.2 Packet Period

This indicates the period in units of the packet timer period. The packet rate can be calculated as follows.
Packet Rate = 1000000/(Packet Period x Packet Timer Period) Hz
For example if the packet timer period is set to 1000 (1 ms). Setting packet ID 20 with a packet period of 50 will
give the following.
Packet 20 Rate = 1000000/(50 x 1000)
Packet 20 Rate = 20 Hz

10.5.3 Baud Rates Packet

Baud Rates Packet
Packet ID
Length
Read / Write
Field # Bytes Offset
1 0
2 1
3 5
4 9
5 13
Table 132: Baud Rates Packet
10.5.3.1 Supported Baud Rate
Note: Not all Advanced Navigation products support minimum and maximum baud rates.
Supported Baud Rates - Bits 0-30
2400
4800
9600
19200
38400
57600
115200
v2.4
Data Type Size
u8 1
u32 4
u32 4
u32 4
4
182
17
Read / Write
Description
Permanent
Primary RS232 and RS422 see
Baud Rate
bit #31: 0 = RS232, 1 = RS422
GPIO 1 & 2 Maximum Baud Rate 250000 see
Supported Baud Rate
Auxiliary RS232 see
bit #31: 0 = RS232, 1 = RS422
Reserved (set to zero)
