Advanced Navigation Certus OEM Reference Manual page 111

Certus Reference Manual • Configuring and Monitoring Certus
8.2.7.2 Sensor Ranges
Note: The sensor range can only be modified for Certus. Certus Evo only offers a fixed sensor range.
See 5.1 Navigation Specifications
The Sensor Ranges dialogue is used to set the dynamic range of the sensors. If the user is experiencing over-
range events during operation, these settings should be used to increase the range of the sensor which is
reporting the over-range. The lowest ranges give the best performance, the user should make changes slowly
and monitor the results.
Figure 77: Manager Sensor Ranges Dialogue
8.2.7.3 Filter Options
For most applications the default filter options should be used and only the vehicle profile set. If in doubt please
contact support@advancednavigation.com.
Figure 78: Manager Filter Options
v2.4
for sensor range specifications.
Page 98 2024-12-17
