Certus Reference Manual • Interfacing
9.6.1.21 Pressure Depth Transducer (deprecated)
Type
:
GPIO Port
:
Auxiliary
:
Description :

9.6.1.22 Left Wheel Speed Sensor

Type
:
GPIO Port
:
Auxiliary
:
Description
:

9.6.1.23 Right Wheel Speed Sensor

Type
:
GPIO Port
:
Auxiliary
:
Description
:
9.6.1.24 Wheel Speed Sensor
Type
:
GPIO Port
:
Auxiliary
:
Description :

9.6.1.25 Wheel Encoder Phase A

Type
:
v2.4
Frequency Input
1, 2
Receive
This function is designed for interfacing with a legacy pressure depth transducer. These
are no longer available and the function is now deprecated.
Frequency Input
1, 2
Receive
This function is designed for the left wheel of a vehicle with dual wheel speed sensors.
Frequency Input
1, 2
Receive
This function is designed for the right wheel of a vehicle with dual wheel speed sensors.
Frequency Input
1, 2
Receive
This function is designed for high resolution vehicle speed sensors and wheel speed
sensors. It expects a normally low input with a high state for the trigger. If the pulse length
is more than 0.1 metres the odometer input function should be used, if it is less than 0.1
metres the wheel speed sensor function should be used. Contact technical support via
email at support@advancednavigation.com
sensor.
Parameter
Trigger
Maximum Frequency
Maximum Pulse Rate
Table 34: Wheel Speed Sensor Specifications
Frequency Input
for with help integrating with your speed
Value
Low → High
40 MHz
4,294,967,295 pulses/metre
