9.6.1.12 Event 1 Input
Type
:
GPIO Port
:
Auxiliary
:
Description :
9.6.1.13 Event 2 Input
Type
:
GPIO Port
:
Auxiliary
:
Description :
9.6.1.14 Odometer Direction, Forward Low
Type
:
GPIO Port
:
Auxiliary
:
Description :
9.6.1.15 Odometer Direction, Forward High
Type
:
GPIO Port
:
Auxiliary
:
Description :
9.6.1.16 Reverse Alignment, Forward Low
Type
:
GPIO Port
:
Auxiliary
:
Description :
v2.4
Digital Input
1, 2
Receive
This function is designed to allow external events to be recorded by Certus. The event is
recorded in the Filter Status (see
resets after the next packet is output. The event triggers on a transition from low to high.
Digital Input
1, 2
Receive
This function is designed to allow external events to be recorded by Certus. The event is
recorded in the Filter Status (see
resets after the next packet is output. The event triggers on a transition from low to high.
Digital Input
1, 2
Receive
This function is designed to take a reversing indication input for direction with an
odometer or wheel encoder. It should be used in combination with Odometer Input or
Wheel Speed Sensor.
Digital Input
1, 2
Receive
This function is designed to take a reversing indication input for direction with an
odometer or wheel encoder. It should be used in combination with Odometer Input or
Wheel Speed Sensor.
Digital Input
1, 2
Receive
This function is designed to reverse the alignment settings for vehicles that can have two
vehicle forward directions, such as locomotives.
10 Advanced Navigation Packet
10 Advanced Navigation Packet
Page 130
Protocol), and
Protocol), and
