Certus Reference Manual • Using Certus

7.13.1 Network RTK Corrections (NTRIP)

NTRIP can be configured as follows:
1. Using the Certus web UI
2. Using the Certus Manager application, select
3. Using the Spatial Manager for Android application. This is convenient for field testing or when temporary
RTK corrections are required, for example for performance trials. Download from the
Any of these NTRIP clients can connect to a network RTK service to stream RTK corrections to Certus. This
requires that the client is connected to the internet, and a valid subscription with a local network RTK service.
Contact Support if you need assistance in setting up for network RTK corrections.

7.13.2 Radio Modem RTK Corrections

Figure 20: Trimble R4 Base Station
Base station radio modem RTK corrections require both a base station and a radio modem receiver. The base
station is set up at a fixed location and transmits corrections to the radio modem receiver that is connected to
the mobile Certus unit (the "rover"). The radio modem receiver and Certus unit must remain within radio range
of the base station to receive these corrections. The base station should be located no more than 50 km from
the Certus, and ideally closer. Advanced Navigation recommends contacting a local surveying company for
assistance setting up a base station.

7.13.3 RTCM Messages

The following RTCM v3.3 messages are recommended for the internal GNSS receiver in Certus.
Message Num- Description
ber
1005 Stationary RTK reference station ARP
1006 Stationary RTK reference station ARP with
antenna height
1007 Antenna descriptor
v2.4
8.1.3.13 NTRIP Client
8.2.8.6 NTRIP Client
Page 49
in the Configuration Menu.
under the Tools menu.
Figure 21: Trimble TDL 450L Radio Modem
Google Play store.
