Certus Reference Manual • Configuring and Monitoring Certus
The table below lists the supported constellations and the corresponding GNSS sample rate depending upon the
number of constellations selected. When setting the data ports, the packet rate of the
Data Packet is automatically adjusted to the next lower integer multiple of the sample period.
# of Constellations
1
2
3
4
5
Table 26: Supported constellations and the corresponding GNSS sample rate
8.2.7.17 CAN Settings
The CAN Settings page allows you to enable or disable the CAN functionality. If the user is connecting to Certus
via the primary port then these settings can be ignored. The default for CAN is Enabled at 1,000,000 baud rate. A
CANOpen EDS file is available. Contact
Figure 92: Manager CAN Settings Dialogue
8.2.8 Tools Menu
The Tools menu contains tools for performing certain procedures with Certus.
Figure 93: Manager Tools Menu
v2.4
Constellation Con-
figurations
GPS
BDS, GLO, GAL, NVC
GPS + GLO
GPS + GAL
All other combinations
All combinations
All combinations
All combinations
support@advancednavigation.com
Packet
Period
40 ms
50 ms
67 ms
72 ms
100 ms
125 ms
143 ms
200 ms
Page 110
10.4.38 Raw Satellite
Packet
Rate
25 Hz
20 Hz
15 Hz
14 Hz
10 Hz
8 Hz
7 Hz
5 Hz
to obtain a copy of this file.
