Flowmeter Proline 200 PROFINET with Ethernet-APL
5.2.9
Preparing the measuring device
Carry out the steps in the following order:
1.
Mount the sensor and transmitter.
2.
Sensor connection housing: Connect connecting cable.
3.
Transmitter: Connect connecting cable.
4.
Transmitter: Connect signal cable and cable for supply voltage.
NOTICE
Insufficient sealing of the housing!
Operational reliability of the measuring device could be compromised.
‣
Use suitable cable glands corresponding to the degree of protection.
1.
Remove dummy plug if present.
2.
If the measuring device is supplied without cable glands:
Provide suitable cable gland for corresponding connecting cable.
3.
If the measuring device is supplied with cable glands:
Observe requirements for connecting cables → 13.
5.3
Connecting the measuring device
NOTICE
Limitation of electrical safety due to incorrect connection!
‣
Have electrical connection work carried out by appropriately trained specialists only.
‣
Observe applicable federal/national installation codes and regulations.
‣
Comply with local workplace safety regulations.
‣
Always connect the protective ground cable before connecting additional cables.
‣
For use in potentially explosive atmospheres, observe the information in the device-specific
Ex documentation.
5.3.1
Connecting the compact version
Connecting the transmitter
The connection of the transmitter depends on the following order code:
"Electrical connection":
• Option A, B, C, D: terminals
• Option I: device plug
Endress+Hauser
Electrical connection
23
