Proline Promass H 300 PROFINET
Endress+Hauser
Measurement channel numbers
Symbol Meaning
Measurement channel 1 to 4
The measurement channel number is displayed only if more than one channel is present for the same measured
variable type (e.g. Totalizer 1 to 3).
Diagnostic behavior
The diagnostic behavior pertains to a diagnostic event that is relevant to the displayed measured variable.
For information on the symbols →  151
The number and display format of the measured values can be configured via the
Format display parameter (→  111).
8.3.2

Navigation view

In the submenu
1
2
/../Operation
Access stat.disp
Locking status
Display
5
1 Navigation view
2 Navigation path to current position
3 Status area
4 Display area for navigation
5 Operating elements →  55
Navigation path
The navigation path - displayed at the top left in the navigation view - consists of the
following elements:
• In the submenu:
Display symbol for menu
• In the wizard:
Display symbol for wizard
↓
Examples
For more information about the icons in the menu, refer to the "Display area" section
→  52
2
0091-1 3
Operator
4
5
A0013993-EN
Omission symbol for
operating menu levels in
between
↓
/ ../
/ ../
Operation options
In the wizard
1
/../Select medium
Select medium
Liquid
Name of current
• Submenu
• Wizard
• Parameters
↓
Display
Display
3
4
A0013995-EN
51
