Technical data
Operable flow range
Output signal
54
Flow characteristic values in US units
Nominal diameter
[in]
⁵⁄₃₂
⁵⁄₁₆
1)
½K
½
1
1) Conical version (corresponds to DN 12)
Recommended measuring range
Flow limit →  60
Over 1000 : 1
16.4

Output

Pulse/frequency/switch output
Function
Version
Maximum output values
Voltage drop
Pulse output
Pulse width
Maximum pulse rate
Pulse value
Assignable measured
variables
Frequency output
Output frequency
Damping
Pulse/pause ratio
Recommended
Flow rate
Maximum full scale value
[gal/s]
0.035
0.13
0.32
0.44
1.33
Can be set to:
• Pulse
Quantity-proportional pulse with pulse width to be configured.
• Automatic pulse
Quantity-proportional pulse with on/off ratio of 1:1
• Frequency
Flow-proportional frequency output with 1:1 on/off ratio
• Switch
Contact for displaying a status
Option FA: IO-Link, 1 pulse/frequency/switch output
Active, high-side
Option FA: IO-Link, 1 pulse/frequency/switch output
• DC 30 V
• 100 mA
Option FA: IO-Link, 1 pulse/frequency/switch output
At 100 mA: ≤ DC 3 V
Configurable: 0.05 to 2 000 ms
10 000 Impulse/s
Configurable
Volume flow
Configurable: 0 to 10 000 Hz
Configurable: 0 to 999.9 s
1:1
Dosimag IO-Link
Factory settings
Low flow cut off
Pulse value
(v ~ 0.13 ft/s)
[oz fl] [oz fl/s]
0.0002 0.02
0.001 0.08
0.004 0.25
0.004 0.25
0.007 0.53
