For STS module illustration, please refer to Figure 5-26.
(STS Module for 20 ~ 80kVA UPS)
LED Indicator
Handle
Switch

5.7.1 STS Module Installation

The hot swappable STS module has been installed inside the UPS in the Delta factory
before shipment. If the STS module is removed for some reasons and you want to re-install
it, please follow the steps below:
NOTE:
1. Only qualified service personnel can perform the following STS module
2. The STS module is heavy (refer to the table below). At least two people are
1
Modulon DPH Series
Size (W × D × H)
444.5 × 575.6 × 86 mm
(17.5" × 22.7" × 3.4")
(Figure 5-26: STS Module)
installation procedures.
required for handling.
Rating
20 ~ 80kVA UPS
20 ~ 120kVA UPS
(STS Module for 20 ~ 120kVA UPS)
444.5 × 620.4 × 130.6 mm
LED Indicator
Handle
Switch
Handle
Weight of STS Module
5-30
Size (W × D × H)
(17.5" × 24.4" × 5.1")
> 11 kg (24.25 lb)
> 16 kg (35.27 lb)
).
