Table 68: Power Losses of Inverter Modules with dU/dt Filter, 150 m (492 ft) Motor Cables, 441–500 V
Model code
iC7-60SAIN05-385A
iC7-60SAIN05-480A
iC7-60SAIN05-590A
iC7-60SAIN05-658A
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
iC7-60SAIN05-1000
iC7-60SAIN05-1100
iC7-60SAIN05-1260
iC7-60SAIN05-1450
iC7-60SAIN05-1710
iC7-60SAIN05-1760
iC7-60SAIN05-1960
iC7-60SAIN05-2150
iC7-60SAIN05-2510
iC7-60SAIN05-2640
iC7-60SAIN05-2880
iC7-60SAIN05-3060
iC7-60SAIN05-3280

Technical Data

10.9
Table 69: Mains connection, AFE/GC modules
Technical item or function
Nominal AC voltage
Nominal DC voltage
Mains frequency
Mains network
Displacement power factor (DPF)
144
| Danfoss Drives Oy © 2024.03
Frame Rated current
I [A]
L
IR10 385
480
531
IR11 590
658
730
820
2 x IR10 920
1030
2 x IR11 1150
1300
1570
3 x IR11 1750
1900
2040
2340
4 x IR11 2480
2630
2770
3050
3 kHz DPWM
Total power losses [kW]
3.5
4.6
5.2
5.1
5.8
6.6
7.8
8.7
9.9
9.9
11.4
14.6
15.2
16.6
18.1
21.8
21.6
23.2
24.7
28.1
Technical data
Voltage class 5: 3 x 380–500 V AC (–15%...+10%)
Voltage class 5: 465–740 V DC
45–66 Hz
TN-S, TN-C, IT and TT.
(Supply voltage limited to 500 V AC for corner-grounded net-
works.)
AFE: 1
Main cooling channel power
losses [kW]
3.3
4.2
4.8
4.7
5.4
6.2
7.2
8.0
9.2
9.2
10.6
13.6
14.2
15.5
16.9
20.2
20.1
21.6
23.0
26.1
