DH-SMT/SI
Pilot-controlled PCVQ DN 100 - DN 250 (PN 16, PN 25)
Technical data, see rating plates and the PCV
data sheet.
DN 100, DN 125
Assembly kit valve unit PCV-VFQ 21
Cu pipe Ø 6 × 1 × 1500 mm
Cu pipe Ø 10 × 1 × 3000 mm
DN 150, DN 250
Assembly kit valve unit PCV-VFQ 21
Cu pipe Ø 6 × 1 × 1500 mm
Cu pipe Ø 10 × 1 × 3000 mm
VI.JA.G2.02
© Danfoss 11/2006
Throttling element
Throttling element
Pilot controller DN 25
AVP-F
Pilot controller DN 40
AVP-F
