Design Guide | iC7 Series Air-cooled System Modules
1
2
3
4
Figure 42: The Star Coupler Board with 16 Ports
1
Board configuration status indicator
3
Power unit connection status indicators
5
+24 V power supply (X65)
7
Control link status indicator
9
Ethernet link activity indicator
1
Figure 43: Control Connection
1
Control board
58
| Danfoss Drives Oy © 2024.03
2
5
6
7
8
9
10
2
+24 V power status indicator
4
Fiber connection to the power unit (X301–X316)
6
Fiber connection to the control board (X90)
8
Ethernet speed indicator
10
Ethernet port (X7)
2
Power unit
AJ389643111587en-000101 / 172F6361A
