Design Guide | iC7 Series Air-cooled System Modules

Dimensions of the Control Unit

10.2.24
Figure 85: Dimensions of the Control Unit in mm (in), Example Configuration
Danfoss Drives Oy © 2024.03
83.4
(3.28)
234
(9.21)
297
(11.69)
79.3
(3.12)
AJ389643111587en-000101 / 172F6361A |
103
