Design Guide | iC7 Series Air-cooled System Modules

Checking the Delivery

4.3
1.
Examine the packaging and the product for transport damage.
a.
If the product was damaged during transport, contact the cargo insurance company or the carrier.
2.
Make sure that the items supplied and the information on the product label correspond to the order confirmation.
a.
If the delivery does not match your order, contact the vendor immediately.

Description of the Frame Designation

4.4
A frame designation is used to refer to different types of iC7 series system modules. The frame designation describes the function,
mechanical variant, and size of the system module.
The frame designation can have this format, for example: IM10.
Table 4: Description of the Frame Designation
Code Description
Function
I
I = Inverter
A = Active front-end/Grid converter
Mechanical variant
M
M = System module
R = System module with integration unit
Size
10
10
11

Weights of the System Modules

4.5
Table 5: Weights of the System Modules
Frame No
integratio
n unit [kg
(lb)]
AM10/ 65
IM10
(143.3)
AM11/ 75
IM11
(165.3)
IR10 –
IR11 –
16
| Danfoss Drives Oy © 2024.03
Short Short Standard
integratio integratio integratio
n unit n unit n unit
without with CM without
filter, filter, filter,
+AE01 [kg +AEC1 +AE10 [kg
(lb)] [kg (lb)] (lb)]
(1)
– – –
– – –
92 101 95
(202.8) (222.7) (209.4)
102 119 110
(224.9) (262.4) (242.5)
Standard Standard Standard
integratio integratio integratio
n unit n unit n unit
with dU/ with dU/ with CM
dt Filter, dt and filter,
+AEU1 CM filter, +AEC2
[kg (lb)] +AEU2 [kg (lb)]
[kg (lb)]
– – –
– – –
140 145 109
(308.6) (319.7) (240.3)
185 194 127
(407.9) (427.7) (280.0)
IP00 [kg IP00 with
(lb)] an IP54
cooling
channel
[kg (lb)]
– –
– –
– –
– –
AJ389643111587en-000101 / 172F6361A
