Design Guide | iC7 Series Air-cooled System Modules
Dimensions of the Short Integration Unit for AFE Module
10.2.16
551
(21.69)
37
(1.45)
Figure 76: Dimensions of the Short Integration Unit for AFE Module in mm (in)
B
Front
94
| Danfoss Drives Oy © 2024.03
B
140
(5.51)
235
(9.25)
537
(21.14)
4 X 45= 180
(7.09)
9
(0.35)
2 x (9 x 37)
162
(6.38)
14
(0.55)
C
5 x Ø6
90˚ Ø9
C
Back
AJ389643111587en-000101 / 172F6361A
