Dimensions of the AFE Module with the Short Integration Unit, AR11

10.2.10
553
(21.77)
500
(19.68)
Figure 70: Dimensions of the AFE Module with the Short Integration Unit in mm (in), AR11
A
Front
88
| Danfoss Drives Oy © 2024.03
A
211
(7.72)
90 28
(1.97) (1.10)
235
(9.25)
2 x (15 x 17)
(0.07 x (0.59 x 0.66))
4 x 45 = 180 27.5
(1.77) (1.08)
85 269
(3.35) (10.6)
B
Back
B
172
(6.77)
Ø13
(0.51)
