Design Guide | iC7 Series Air-cooled System Modules
Table 48: DC Fuses for AFE, 465–740 V DC (continued)
(1)
Model code
iC7-60SA3x05-580AE00
iC7-60SA3x05-650AE00
iC7-60SA3x05-730AE00
iC7-60SA3x05-816AE00
iC7-60SA3x05-920E00
iC7-60SA3x05-1030E00
iC7-60SA3x05-1210E00
iC7-60SA3x05-1410E00
iC7-60SA3x05-1630E00
iC7-60SA3x05-1860E00
iC7-60SA3x05-2120E00
iC7-60SA3x05-2450E00
iC7-60SA3x05-2800E00
iC7-60SA3x05-3270E00
iC7-60SA3x05-3650E00
iC7-60SA3x05-4080E00
iC7-60SA3x05-4500E00
iC7-60SA3x05-4900E00
1) Model codes starting with iC7-60SA3A05 or iC7-60SA3H05
DC Fuses for Inverter Modules, 465–740 V DC
10.5.4
Table 49: DC Fuses for Inverter Modules, 465–740 V DC
Model code
iC7-60SAIN05-385AE00
iC7-60SAIN05-480AE00
iC7-60SAIN05-590AE00
iC7-60SAIN05-658AE00
iC7-60SAIN05-730AE00
iC7-60SAIN05-820AE00
iC7-60SAIN05-880AE00
Danfoss Drives Oy © 2024.03
Frame Rated
current
I [A]
L
AM11/AR11 580
650
730
816
2 x AM10/ 2 x 920
AR10
1030
2 x AM11/ 2 x 1210
AR11
1410
1630
3 x AM11/ 3 x 1860
AR11
2120
2450
4 x AM11/ 4 x 2800
AR11
3270
5 x AM11/ 5 x 3650
AR11
4080
6 x AM11/ 6 x 4500
AR11
4900
Frame Rated
current
I [A]
L
IM10/IR10 385
480
590
IM11/IR11 658
730
820
880
Number Fuse size Mersen part number
of fuses
2 73 PC73UD90V13CTF
PC73UD90V13CTF
PC73UD85V14CTF
PC73UD85V14CTF
4 73 PC73UD13C800TF
PC73UD10C1000TF
4 73 PC73UD90V13CTF
PC73UD85V14CTF
PC73UD85V14CTF
6 73 PC73UD90V13CTF
PC73UD90V13CTF
PC73UD85V14CTF
8 73 PC73UD90V13CTF
PC73UD85V14CTF
10 73 PC73UD85V14CTF
PC73UD85V14CTF
12 73 PC73UD85V14CTF
PC73UD85V14CTF
Number Fuse size Mersen part number
of fuses
2 73 PC73UD13C630TF
PC73UD13C800TF
PC73UD10C1000TF
2 73 PC73UD90V13CTF
PC73UD90V13CTF
PC73UD85V14CTF
PC73UD85V14CTF
Fuse U
n
[V]
900
900
850
850
1250
1000
900
850
850
900
900
850
900
850
850
850
850
850
Fuse U
n
[V]
1250
1250
1000
900
900
850
850
AJ389643111587en-000101 / 172F6361A |
Fuse I
n
[A]
1250
1250
1400
1400
800
1000
1250
1400
1400
1250
1250
1400
1250
1400
1400
1400
1400
1400
Fuse I
n
[A]
630
800
1000
1250
1250
1400
1400
125
