Design Guide | iC7 Series Air-cooled System Modules
Dimensions of the Pre-charging Unit, IEC
10.2.30
30
60
(1.18)
(2.36)
15
(0.59)
118
(4.64)
240
(9.45)
18
(0.71)
230
(9.05)
Figure 92: Dimensions of the Pre-charging Unit in mm (in), IEC
Danfoss Drives Oy © 2024.03
292
(11.5)
240
(9.45)
Ø6
60
(0.24)
(2.36)
239
(9.41)
263
(10.35)
AJ389643111587en-000101 / 172F6361A |
109
