Motor Cable Sizes Recommendation for Inverter Modules, UL 480 V
10.4.6
Table 45: Motor Cable Sizes Recommendation for Inverter Modules, UL 480 V
Model code Frame
iC7-60SAIN05-385A IM10
iC7-60SAIN05-480A
iC7-60SAIN05-590A
iC7-60SAIN05-658A IM11
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
iC7-60SAIN05-1000 2 x IM10
iC7-60SAIN05-1100
iC7-60SAIN05-1260 2 x IM11
iC7-60SAIN05-1450
iC7-60SAIN05-1710
iC7-60SAIN05-1760 3 x IM11
iC7-60SAIN05-1960
iC7-60SAIN05-2150
iC7-60SAIN05-2510

Motor Cable Size Recommendations for Inverter Modules with Integration Units, UL 480 V

10.4.7
Table 46: Motor Cable Size Recommendations for Inverter Modules with Integration Units, UL 480 V
Model code Frame
iC7-60SAIN05-385A IR10
iC7-60SAIN05-480A
iC7-60SAIN05-590A
122
| Danfoss Drives Oy © 2024.03
I [A] Motor cable Cu
N
2
[mm ]
394 2 x 300MCM
490 3 x 250MCM
543 3 x 300MCM
603 3 x 350MCM
672 4 x 250MCM
746 4 x 300MCM
838 4 x 350MCM
940 6 x 4/0
1052 6 x 250MCM
1174 6 x 300MCM
1328 8 x 250MCM
1603 8 x 350MCM
1807 9 x 350MCM
1 940 9 x 350MCM
2 083 12 x 250MCM
2 389 12 x 300MCM
I [A] Motor cable Cu
N
2
[mm ]
394 2 x 300MCM
490 3 x 250MCM
543 3 x 300MCM
Motor cable Terminal
termination, maximum
Panduit terminal cable size
part number
LCAX300-12-X 350MCM
LCAX250-12-X 350MCM
LCAX300-12-X 350MCM
LCAN350-12-X 350MCM
LCAX250-12-X 350MCM
LCAX300-12-X 350MCM
LCAN350-12-X 350MCM
LCAX4/0-12-X 350MCM
LCAX250-12-X 350MCM
LCAX300-12-X 350MCM
LCAX250-12-X 350MCM
LCAN350-12-X 350MCM
LCAN350-12-X 350MCM
LCAN350-12-X 350MCM
LCAX250-12-X 350MCM
LCAX300-12-X 350MCM
Motor cable Terminal
termination, maximum
Panduit terminal cable size
part number
LCAX300-12-X 500MCM
LCAX250-12-X 500MCM
LCAX300-12-X 500MCM
AJ389643111587en-000101 / 172F6361A
Number of Maximum
grounding number of
terminals conductor
(bolt size) s per
phase
(bolt size)
1 (M6) 3 (M10)
1 (M6) 3 (M10)
1 (M6) 3 (M10)
1 (M6) 4 (M12)
1 (M6) 4 (M12)
1 (M6) 4 (M12)
1 (M6) 4 (M12)
2 (M6) 6 (M10)
2 (M6) 6 (M10)
2 (M6) 8 (M12)
2 (M6) 8 (M12)
2 (M6) 8 (M12)
3 (M6) 12 (M12)
3 (M6) 12 (M12)
3 (M6) 12 (M12)
3 (M6) 12 (M12)
Number of Maximum
grounding number of
terminals conductor
(bolt size) s per
phase
(bolt size)
1 (M8) 4 (M10)
1 (M8) 4 (M10)
1 (M8) 4 (M10)
