Table 57: Current Ratings for Inverter Module, 400 V AC (465–650 V DC) (continued)
Model code
iC7-60SAIN05-658A
iC7-60SAIN05-730A
iC7-60SAIN05-820A
(1)
iC7-60SAIN05-880A
iC7-60SAIN05-1000
iC7-60SAIN05-1100
iC7-60SAIN05-1260
iC7-60SAIN05-1450
(1)
iC7-60SAIN05-1710
iC7-60SAIN05-1760
iC7-60SAIN05-1960
iC7-60SAIN05-2150
(1)
iC7-60SAIN05-2510
iC7-60SAIN05-2640
iC7-60SAIN05-2880
iC7-60SAIN05-3060
(1)
iC7-60SAIN05-3280
iC7-60SAIN05-3420
iC7-60SAIN05-3600
iC7-60SAIN05-4060
iC7-60SAIN05-4320
iC7-60SAIN05-4870
1) For high overload ratings, derating starts from 35 °C (95 °F) in combinations with +AEU1, +AEU2.
Danfoss Drives Oy © 2024.03
Frame AC current
I [A] I [A]
N L
IM11/ 672 658
IR11
746 730
838 820
899 880
2 x IM10/ 1021 1000
IR10
1123 1100
2 x IM11/ 1287 1260
IR11
1481 1450
1746 1710
3 x IM11/ 1797 1760
IR11
2001 1960
2195 2150
2563 2510
4 x IM11/ 2695 2640
IR11
2940 2880
3124 3060
3349 3280
5 x IM11/ 3492 3420
IR11
3675 3600
4145 4060
6 x IM11/ 4410 4320
IR11
4972 4870
Typical motor power,
400 V AC
I [A] I [A] P [kW]
H peak L
547 930 355
606 1031 400
681 1158 450
731 1243 500
830 1411 560
913 1553 630
1050 1785 710
1210 2057 800
1420 2414 900
1470 2499 1000
1630 2771 1100
1790 3043 1200
2090 3553 1400
2200 3740 1500
2400 4080 1600
2540 4318 1700
2730 4641 1800
2840 4828 1900
2990 5083 2000
3370 5729 2200
3590 6103 2400
4050 6885 2700
AJ389643111587en-000101 / 172F6361A |
DC
current
P [kW] I [A]
H N-DC
250 721
315 813
355 913
400 1015
450 1138
500 1280
560 1441
630 1625
710 1826
800 2030
900 2234
1000 2436
1100 2841
1200 3045
1300 3247
1400 3450
1500 3652
1500 3856
1600 4058
1800 4465
1900 4871
2200 5478
