Design Guide | iC7 Series Air-cooled System Modules
Table 46: Motor Cable Size Recommendations for Inverter Modules with Integration Units, UL 480 V (continued)
Model code Frame
iC7-60SAIN05-658A IR11
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
iC7-60SAIN05-1000 2 x IR10
iC7-60SAIN05-1100
iC7-60SAIN05-1260 2 x IR11
iC7-60SAIN05-1450
iC7-60SAIN05-1710
iC7-60SAIN05-1760 3 x IR11
iC7-60SAIN05-1960
iC7-60SAIN05-2150
iC7-60SAIN05-2510

Fuses

10.5

List of Fuse Size Information

10.5.1
The fuse size tables for the air-cooled system modules can be found with these links.
10.5.2 AC Fuses for AFE, 380–500 V AC
l
10.5.3 DC Fuses for AFE, 465–740 V DC
l
10.5.4 DC Fuses for Inverter Modules, 465–740 V DC
l
AC Fuses for AFE, 380–500 V AC
10.5.2
Table 47: AC Fuses for AFE, 380–500 V AC
(1)
Model code
iC7-60SA3x05-317AE00
iC7-60SA3x05-400AE00
iC7-60SA3x05-514AE00
Danfoss Drives Oy © 2024.03
I [A] Motor cable Cu
N
2
[mm ]
603 3 x 350MCM
672 4 x 250MCM
746 4 x 300MCM
838 4 x 350MCM
940 6 x 4/0
1052 6 x 250MCM
1174 6 x 300MCM
1328 8 x 250MCM
1603 8 x 350MCM
1807 9 x 350MCM
1 940 9 x 350MCM
2 083 12 x 250MCM
2 389 12 x 300MCM
Frame Rated Number
current of fuses
I [A]
L
AM10/ 317 3
AR10
400
514
Motor cable Terminal
termination, maximum
Panduit terminal cable size
part number
LCAX350-12-X 500MCM
LCAX250-12-X 500MCM
LCAX300-12-X 500MCM
LCAX350-12-X 500MCM
LCAX4/0-12-X 500MCM
LCAX250-12-X 500MCM
LCAX300-12-X 500MCM
LCAX250-12-X 500MCM
LCAX350-12-X 500MCM
LCAX350-12-X 500MCM
LCAX350-12-X 500MCM
LCAX250-12-X 500MCM
LCAX300-12-X 500MCM
Fuse Mersen part
size
(2)
number
33 PC33UD69V550TF
PC33UD69V550TF
PC33UD69V700TF
AJ389643111587en-000101 / 172F6361A |
Number of Maximum
grounding number of
terminals conductor
(bolt size) s per
phase
(bolt size)
1 (M8) 4 (M10)
1 (M8) 4 (M10)
1 (M8) 4 (M10)
1 (M8) 4 (M10)
2 (M8) 8 (M10)
2 (M8) 8 (M10)
2 (M8) 8 (M10)
2 (M8) 8 (M10)
2 (M8) 8 (M10)
3 (M8) 12 (M10)
3 (M8) 12 (M10)
3 (M8) 12 (M10)
3 (M8) 12 (M10)
Fuse U Fuse I Minimu
n n
m I
[V] [A]
cp,mr
[A]
690 550 3300
690 550 3300
690 700 4800
