Dimensions for DC Fuses, IM11
10.2.21
85
269
(3.35)
(10.59)
Figure 82: Dimensions for DC Fuses in mm (in), IM11
A
Dimensions without DC fuses
100
| Danfoss Drives Oy © 2024.03
A
161
(6.34)
46
(1.81)
B
159
121
(4.76)
(6.26)
B
Dimensions with DC fuses
161
(6.34)
46
(1.81)
AJ389643111587en-000101 / 172F6361A
