Dimensions of the AFE Module, AR10

10.2.7
552
(21.73)
500
(19.68)
115.5
(4.54)
25.5 (1.0)
160.5
(6.31)
48 (1.88) 183
(7.20)
205.5
70.5 (2.77)
(8.09)
5 x Ø5.5
(0.20 x 0.22)
8 x Ø5.5
90° Ø9.5
166.5
(6.55)
231
(9.09)
Figure 67: Dimensions of the AFE Module in mm (in), AR10
B
Front
The additional front fixing plate adds 2 mm to the overall height. The plate is optional.
