Design Guide | iC7 Series Air-cooled System Modules
Table 50: Abbreviations Used in the Rating Tables
Abbreviation
I
N
I
L
I
H
I
peak
I
N-DC
S
N
P
L
P
H
Current Ratings for Regenerative AFE Module, 400 V AC (465–650 V DC)
10.6.2
Table 51: Current Ratings for Regenerative AFE Module, 400 V AC (465–650 V DC)
Model code
iC7-60SA3A05-317A
iC7-60SA3A05-400A
iC7-60SA3A05-514A
iC7-60SA3A05-580A
iC7-60SA3A05-650A
iC7-60SA3A05-730A
iC7-60SA3A05-816A
iC7-60SA3A05-920A
iC7-60SA3A05-1030
iC7-60SA3A05-1210
iC7-60SA3A05-1410
iC7-60SA3A05-1630
iC7-60SA3A05-1860
iC7-60SA3A05-2120
iC7-60SA3A05-2450
Danfoss Drives Oy © 2024.03
Description
Nominal current. If the process does not require any overloadability or the process does
not include any load variation or margin for overloadability, the dimensioning can be
done according to this current.
Nominal current with low overload (110%). Allows a +10% load variation for 1 minute
every 5 minutes.
Nominal current with high overload (150%). Allows a +50% load variation for 1 minute
every 5 minutes.
Start current. Available for 3 s at start, then as long as the system module temperature
allows. Relevant for inverter modules.
DC current
Apparent power
Output power at low overload
Output power at high overload
Frame AC ratings
S [kVA] I
N N
AM10/ 220 324
AR10
278 409
357 525
AM11/ 402 593
AR11
451 664
506 746
566 833
2 x 638 940
AM10/
714 1052
AR10
2 x 839 1236
AM11/
977 1440
AR11
1130 1664
3 x 1289 1899
AM11/
1469 2165
AR11
1698 2501
[A] I [A] I [A]
L H
317 263
400 327
514 426
580 464
650 525
730 591
816 678
920 735
1030 850
1210 980
1410 1140
1630 1360
1860 1575
2120 1838
2450 2030
DC ratings
I [A] P [kW]
N-DC L
371 216
469 272
602 349
677 394
760 442
852 496
953 555
1075 625
1203 700
1413 822
1647 958
1903 1107
2172 1263
2475 1440
2861 1664
AJ389643111587en-000101 / 172F6361A |
P [kW]
H
179
223
290
316
357
402
461
500
578
666
775
924
1070
1248
1379
