Design Guide | iC7 Series Air-cooled System Modules
1
1
Figure 19: Recommended Installation
1
Inverter module
1
1
Figure 20: Alternative Installation Method
1
Inverter module
Cable Requirements for the LCL Filter Fan Supply
6.6
The LCL Filter fan supply is protected with internal fuses. Use external fuses if the local safety regulations or installation conditions
require fuse protection.
Table 10: DC-link Voltage Supply
Item
Maximum load current
Maximum voltage
Danfoss Drives Oy © 2024.03
2
M
2
Common coupling point at the motor terminals
M
NOTICE
Value
2 A
740 V DC
AJ389643111587en-000101 / 172F6361A |
35
