Dimensions of the LCL Filter, Size 10 and 11

10.2.15
2 x Ø9 (0.35) 5 x Ø5.5 (0.22)
72 Ø25
(0.98)
R10 (2.84)
R7.5
3 x M8
7 x Ø6 (0.24)
90° x Ø9 (0.35)
Figure 75: Dimensions of the LCL Filter in mm (in), Size 10 and 11
Danfoss Drives Oy © 2024.03
300
(11.81)
259
(10.20)
3 x M8
M12
M12
99
(3.90)
189
(7.44) 23
(0.91)
279
(10.98)
280
300
(11.02)
(11.81)
78
(3.07)
39
(1.54)
505
(19.88)
555
(21.85)
Ø13
(0.51)
921
(36.26)
1576
(62.05)
2 x Ø9
(0.35)
584
(22.99)
AJ389643111587en-000101 / 172F6361A |
Ø13
(0.51)
