Design Guide | iC7 Series Air-cooled System Modules
Dimensions for DC Fuses, IR11
10.2.23
85
269
(3.35)
(10.59)
Figure 84: Dimensions for DC Fuses in mm (in), IR11
A
Dimensions with DC fuses
102
| Danfoss Drives Oy © 2024.03
A
824
(32.44)
B
172
(6.77)
870
(34.25)
B
Dimensions without DC fuses
AJ389643111587en-000101 / 172F6361A
