Design Guide | iC7 Series Air-cooled System Modules

Dimensions of the Inverter Module, IR11

10.2.5
555
(21.73)
500
(19.68)
115.5 (4.54)
70.5 (1.0) 160.5 (6.31)
48 (1.88) 183 (7.20)
(8.09)
25.5 (2.77) 205.5
5 x Ø5.5
(0.20 x 0.22)
8 x Ø5.5
90° Ø9.5
166.5
(6.55)
231
(9.09)
Figure 65: Dimensions of the Inverter Module in mm (in), IR11
B
Front
The additional front fixing plate adds 2 mm to the overall height. The plate is optional.
Danfoss Drives Oy © 2024.03
90
(3.54)
12 x M10
37 (1.46)
37 (1.46)
A
2 x Ø9
(0.07 x 0.35)
A - A
166.5 8 x Ø4.5
(6.55) (0.31 x 0.17)
4 x 45 = 180
(1.77)
B
211
(8.31)
28
85
(1.10)
(3.35)
2 x M8
A
235
(9.25)
2 x (15 x 17)
(0.07 x (0.59 x 0.67))
27.5
(1.08)
C
Back
C
172
269
(6.77)
(10.59)
408
(16.03)
AJ389643111587en-000101 / 172F6361A |
Ø13
(0.51)
83
