Design Guide | iC7 Series Air-cooled System Modules
Dimensions for DC Fuses, IM10
10.2.20
85
269
(3.35)
(10.59)
Figure 81: Dimensions for DC Fuses in mm (in), IM10
A
Dimensions without DC fuses
Danfoss Drives Oy © 2024.03
A
122
(4.80)
46
(1.81)
B
159
121
(6.26)
(4.76)
B
Dimensions with DC fuses
AJ389643111587en-000101 / 172F6361A |
122
(4.80)
46
(1.81)
99
