Design Guide | iC7 Series Air-cooled System Modules

Dimensions of the Short Integration Unit for Inverter Module

10.2.18
551
(21.69)
382
(15.04)
(6.55)
Figure 78: Dimensions of the Short Integration Unit for Inverter Module in mm (in)
B
Front
96
| Danfoss Drives Oy © 2024.03
12 x M10
37 (1.46)
37 (1.46)
175
(6.88) A
43
(1.69)
27
(1.06)
A - A
537
196.5
(21.14)
(7.73)
8 x Ø4.5
(0.31 x 0.17)
166.5
4 x 45= 180
(1.77)
B
140 9
(5.51) (0.35)
2 x (9 x 13)
507
(19.96)
394
(15.51)
A
235
(9.25)
2 x (15 x 17)
(0.07 x (0.59 x 0.67))
27.5
(1.08)
C
Back
49
405 (1.93)
49
(15.94)
(1.93)
C
AJ389643111587en-000101 / 172F6361A
