Table 42: Motor Cable Size Recommendations for Inverter Modules, 380–500 V (continued)
Model code Frame
iC7-60SAIN05-1000 2xIM10
iC7-60SAIN05-1100
iC7-60SAIN05-1260 2xIM11
iC7-60SAIN05-1450
iC7-60SAIN05-1710
iC7-60SAIN05-1760 3xIM11
iC7-60SAIN05-1960
iC7-60SAIN05-2150
iC7-60SAIN05-2510
1) The bolt hole spacing is 35 mm. Check the width of the cable lug.
Motor Cable Size Recommendations for Inverter Modules with Integration Units, 380–500 V
10.4.4
Table 43: Motor Cable Size Recommendations for Inverter Modules with Integration Units, 380–500 V
Model code Frame
iC7-60SAIN05-385A IR10
iC7-60SAIN05-480A
iC7-60SAIN05-590A
iC7-60SAIN05-658A IR11
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
iC7-60SAIN05-1000 2xIR10
iC7-60SAIN05-1100
120
| Danfoss Drives Oy © 2024.03
I [A] Motor cable Cu
N
2
[mm ]
1021 6x (3 x 95 + 50)
1123 6x (3 x 95 + 50)
1287 6x (3 x 120 + 70)
1481 8x (3 x 95 + 50)
1746 8x (3 x 120 + 70)
1797 9x (3 x 120 + 70)
2 001 9x (3 x 150 + 70)
2 195 9x (3 x 150 + 70)
2 563 12x (3 x 120 + 70)
I [A] Motor cable Cu
N
2
[mm ]
394 3x (3 x 50 + 25)
490 3x (3 x 70 + 35)
603 3x (3 x 95 + 50)
672 4x (3 x 70 + 35)
746 4x (3 x 95 + 50)
838 3x (3 x 150 + 70)
899 4x (3 x 120 + 70)
1021 6x (3 x 95 + 50)
1123 6x (3 x 95 + 50)
Motor cable Al Maximum
terminal
2
[mm ]
cable size
2
(1)
[mm ]
6x (3 x 120 + 41) 240Cu/Al
6x (3 x 150 + 41) 240Cu/Al
8x (3 x 120 + 41) 300Cu/Al
8x (3 x 150 + 41) 300Cu/Al
8x (3 x 185 + 57) 300Cu/Al
12x (3 x 120 + 41) 300Cu/Al
12x (3 x 120 + 41) 300Cu/Al
12x (3 x 150 + 41) 300Cu/Al
12x (3 x 185 + 57) 300Cu/Al
Motor cable Al Maximum
terminal
2
[mm ]
cable size
2x (3 x 120 + 41) 300 Cu/Al
3x (3 x 120 + 41) 300 Cu/Al
4x (3 x 95+ 29) 300 Cu/Al
4x (3 x 120 + 41) 300 Cu/Al
4x (3 x 150 + 41) 300 Cu/Al
4x (3 x 150 + 41) 300 Cu/Al
4x (3 x 185 + 57) 300 Cu/Al
6x (3 x 120 + 41) 300 Cu/Al
6x (3 x 150 + 41) 300 Cu/Al
