Design Guide | iC7 Series Air-cooled System Modules
Mains Cable Sizes for AFE Modules, 380–500 V
10.4.2
Table 41: Mains Cable Size Recommendations for AFE Modules, 380–500 V
(1)
Model code
iC7-60SA3A05-317AE00
iC7-60SA3A05-400AE00
iC7-60SA3A05-514AAE00
iC7-60SA3A05-580AE00
iC7-60SA3A05-650AE00
iC7-60SA3A05-730AE00
iC7-60SA3A05-816AAE00
iC7-60SA3A05-920E00
iC7-60SA3A05-1030AE00
iC7-60SA3A05-1210E00
iC7-60SA3A05-1410E00
iC7-60SA3A05-1630AE00
iC7-60SA3A05-1860E00
iC7-60SA3A05-2120E00
iC7-60SA3A05-2450AE00
1) Model codes starting with iC7-60SA3A05 or iC7-60SA3H05
Motor Cable Sizes Recommendation for Inverter Modules, 380–500 V
10.4.3
Table 42: Motor Cable Size Recommendations for Inverter Modules, 380–500 V
Model code Frame
iC7-60SAIN05-385A IM10
iC7-60SAIN05-480A
iC7-60SAIN05-590A
iC7-60SAIN05-658A IM11
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
Danfoss Drives Oy © 2024.03
Frame I [A]
N
AM10/AR10 324
409
525
AM11/AR11 593
664
746
833
2xAM10/2xAR10 940
1052
2xAM11/2xAR11 1236
1440
1664
3xAM11/3xAR11 1899
2165
2501
I [A] Motor cable Cu
N
2
[mm ]
394 3x (3 x 50 + 25)
490 3x (3 x 70 + 35)
603 3x (3 x 95 + 50)
672 4x (3 x 70 + 35)
746 4x (3 x 95 + 50)
838 3x (3 x 150 + 70)
899 4x (3 x 120 + 70)
2
Mains cable Cu [mm ]
1x (3 x 150 + 70)
3x (3 x 50 + 25)
3x (3 x 70 + 35)
2x (3 x 150 + 70)
4x (3 x 70 + 35)
4x (3 x 95+ 50)
3x (3 x 150 + 70)
6x (3 x 70 + 35)
4x (3 x 150 + 70)
6x (3 x 120 + 70)
6x (3 x 150 + 70)
6x (3 x 185 + 95)
9x (3 x 120 + 70)
9x (3 x 150 + 70)
9x (3 x 185 + 95)
Motor cable Al Maximum
terminal
2
[mm ]
cable size
2
(1)
[mm ]
2x (3 x 120 + 41) 240Cu/Al
3x (3 x 120 + 41) 240Cu/Al
3x (3 x 150+ 41) 300Cu/Al
4x (3 x 120 + 41) 300Cu/Al
4x (3 x 150 + 41) 300Cu/Al
4x (3 x 150 + 41) 300Cu/Al
4x (3 x 185 + 57) 300Cu/Al
AJ389643111587en-000101 / 172F6361A |
2
Mains cable Al [mm ]
2x (3 x 95 + 29)
3x (3 x 95 + 29)
3x (3 x 120 + 41)
3x (3 x 150 + 41)
4x (3 x 120 + 41)
4x (3 x 150 + 41)
4x (3 x 150 + 41)
4x (3 x 185 + 57)
6x (3 x 150 + 41)
6x (3 x 185 + 57)
8x (3 x 150 + 41)
8x (3 x 185 + 57)
9x (3 x 185 + 57)
12x (3 x 150 + 41)
12x (3 x 185 + 57)
Number of Maximum
grounding number of
terminals conductor
(bolt size) s per
phase
(bolt size)
1/M8 3/M10
1/M8 3/M10
1/M8 3/M10
1/M8 4/M12
1/M8 4/M12
1/M8 4/M12
1/M8 4/M12
