Design Guide | iC7 Series Air-cooled System Modules
Control for 5 X AR 1 1
DC 1 2 3 4 X Z
137H0741
1
Figure 7: Labels on the Control Unit and Star Coupler Board
1
Label on the control unit
There are similar identification labels on the integration units, filters, and other components. For example, the LCL Filter has a power unit
label, like on the system modules. The integration units have an identification label that shows to which system module it belongs.
1
iC7 LCL Filter
M/C :OF7Z3-M-AF-05-816A-A1-C54-F3
LC -Unit S/N: DC12345X - 1234 - DC
L -Unit S/N: DC12345X - 1234 - DC
P/N: 132X9891 S/N: DC12345X - 1234 - DC
VOLTAGE: 3x380-500VAC 50/60Hz
CURRENT: 816A
Switching frequency: 4KHZ
Air Cooled
ENCL :IP54/UL TYPE12 cooling channel
Protection class 1 LCL11
SCCR: 100kA
Danfoss Ltd.22 Wycombe End,HP9 1NB, GB
Figure 8: Labels on the LCL Filter and Integration Unit
1
Power unit label of LCL Filter

Product Label

4.12
The product label gives information about the product.
24
| Danfoss Drives Oy © 2024.03
Danfoss A/S
DK-6430 Nordborg
www.danfoss.com
MADE IN FINLAND
S tar for 5 X AR 1 1
DC 1 2 3 4 X Z
137G2222
2
2
Label on the star coupler board
2
Identification label of integration unit
2
Integration Unit for Power Unit 3/5
DC1234XZ
Main product:
IC7-60SAGC05-3650E00F4+AE10
