Design Guide | iC7 Series Air-cooled System Modules
Table 67: Power Losses of Inverter Modules without Options, 441–500 V
Model code
iC7-60SAIN05-385A
iC7-60SAIN05-480A
iC7-60SAIN05-590A
iC7-60SAIN05-658A
iC7-60SAIN05-730A
iC7-60SAIN05-820A
iC7-60SAIN05-880A
iC7-60SAIN05-1000
iC7-60SAIN05-1100
iC7-60SAIN05-1260
iC7-60SAIN05-1450
iC7-60SAIN05-1710
iC7-60SAIN05-1760
iC7-60SAIN05-1960
iC7-60SAIN05-2150
iC7-60SAIN05-2510
iC7-60SAIN05-2640
iC7-60SAIN05-2880
iC7-60SAIN05-3060
iC7-60SAIN05-3280
Power Losses of Inverter Modules with dU/dt Filter, 150 m (492 ft) Motor Cables, 441–500 V
10.8.7
The specifications for the values in the table
Inverter module
l
441–500 V AC (465–740 V DC)
l
Losses calculated with 500 V AC and 743 V DC
l
With dU/dt filter
l
Switching frequency 3 kHz
l
DPWM modulator
l
Motor cable length a maximum of 150 m
l
Danfoss Drives Oy © 2024.03
Frame Rated current
I [A]
L
IM10 385
480
531
IM11 590
658
730
820
2 x IM10 920
1030
2 x IM11 1150
1300
1570
3 x IM11 1750
1900
2040
2340
4 x IM11 2480
2630
2770
3050
2 kHz SVPWM or 3 kHz DPWM
Total power losses [kW]
2.8
3.6
4.1
4.0
4.6
5.3
6.3
6.9
8.0
7.7
9.0
11.8
11.9
13.1
14.4
17.5
17.0
18.4
19.7
22.6
AJ389643111587en-000101 / 172F6361A |
Main cooling channel power
losses [kW]
2.5
3.3
3.8
3.6
4.2
4.8
5.7
6.2
7.2
7.0
8.3
10.7
10.9
12.0
13.2
16.0
15.5
16.8
18.0
20.6
