Table 25: I/O and Relay Option Signals (continued)
Terminal
X102
X103
Table 26: I/O Terminal Signals (X13)
Terminal Function
11 +24 V
out
12 +24 V
out
13 DI 1
14 DI 2
15 DI 3
16 DI 4
17 DI 5
18 DI 6
19 DGND
20 DGND
21 DO 1
22 DO 2
23 GND
24 GND
31 AO 1
32 +10 V ref.
Danfoss Drives Oy © 2024.03
Function
Relay 2
Relay 3
Description
Control voltage output.
24 V DC (-15...+20%)
Maximum current 200 mA
Short-circuit protected
Configurable digital input, galvanically isolated.
24 V DC, 0 < 5 V, 1 > 15 V.
Input load 7.5 mA constant current + 10 kΩ resistive load, maximum pulse frequency 100 kHz.
Digital input ground, not isolated by default.
When using the internal +24 V
When using the external +24 V DC supply, remove the external jump wire between DGND and GND.
(1)
Configurable digital output.
Push-pull 24 V/50 mA
Open collector (NPN/PNP) 48 V/50 mA
Short-circuit protected
I/O ground.
Ground for digital outputs, +10 V Ref, +24 V
Configurable analog output.
Voltage mode:
• 0...10 V
• R ≥ 1 kΩ
L
• accuracy ≤ ± 0.5% of full scale
• short-circuit protected
Current mode:
• 0...20 mA
≤ 600 Ω
• R
L
• accuracy ≤ ± 0.5% of full scale
• short-circuit protected
10 V (0...+3%), maximum current 10 mA
Connector type
1 x 3 spring force connector 0.25–2.5 mm
1 x 2 spring force connector 0.25–2.5 mm
supply, connect the external jump wire between DGND and GND.
out
, analog inputs, and analog outputs.
out
2
2
