Description of the Model Code

4.8
The model code defines the specifications of the product included in the delivery. It is shown on the product label and the package label.
The model code is made of standard codes and plus codes. Each part of the model code corresponds to the data in your order.
The model code can have this format, for example:
iC7-60SA3A05-816AE00F3+XXXX
Table 6: Description of the Model Code
Code Description
Product group
iC7-60
Product category
SA
SA = system module, air-cooled
Product type
3A
3A = 3~ regenerative AFE
3H = 3~ low-harmonic AFE
GC = Grid converter module, GC
IN = Inverter module, INU
Voltage rating
05
05 = 380–500 V AC
Current rating
-816A
-03A0 = 3 A
-816A = 816 A
-3000 = 3000 A
etc.
Protection rating
E00
E00 = IP00/Open Type
EMC category
F3
F3 = C3
F4 = C4
Options
+XXXX
See
20
| Danfoss Drives Oy © 2024.03
4.9 Options.
