VACON® NXP IP00 Drive Modules
Operating Guide
Code
Description
T.1
Counted operation days
T.2
Counted operation hours
T.3
Output frequency
T.4
Motor current
T.5
Motor voltage
T.6
Motor power
T.7
Motor torque
T.8
DC voltage
T.9
Unit temperature
T.10
Run status
T.11
Direction
T.12
Warnings
0-speed
(1)
T.13
T.14
Subcode
T.15
Module
T.16
Submodule
Tells if the drive was at zero speed (< 0.01 Hz) when the fault showed.
1
8.6 Using the Fault History Menu (M5)
8.6.1 Fault History Menu (M5)
There is a maximum number of 30 faults in the Fault history. The information on each fault shows in the Fault time data record, see
8.5.3 Fault Time Data
Record.
The value line of the main page (H1->H#) shows the number of faults in the fault history. The location indication tells in which order
the faults have shown. The newest fault has the indication H5.1, the second newest H5.2, and so on. If there are 30 faults in the
history, the next fault that shows removes the oldest one (H5.30) from the history.
See the different fault codes in the Faults and Alarms section.
8.6.2 Resetting the Fault History
The Fault History shows 30 latest faults at a time. Use these instructions to reset the history.
Procedure
1.
To find the Fault history menu, scroll down in the main menu until the location indication M5 shows on the first line of the
display.
2.
To go to the Fault history menu from the main menu, push the Menu button Right.
Danfoss A/S © 2023.09
Value
Real Time Data Record
d
yyyy-mm-dd
hh:mm:ss (d)
hh:mm:ss,sss
Hz (hh:mm:ss)
–
A
–
V
–
%
–
%
–
V
–
°C
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Using the Control Panel
AQ351737303996en-000201 / DPD00888 | 93
