Table 19: Minimum Distances between Cables
The distance between ca-
bles [m]
0.3
1.0
Table 20: Maximum Cable Lengths with dU/dt Filter
Maximum cable length with dU/dt filter
100 m (328 ft) at 500 V level
150 m (492 ft) at 690 V level
For longer cable lenghts, contact Danfoss.
1

6.7.2 Installing the Cables, FR8

Follow these instructions to install the cables.
For information on how to comply with the UL regulations in cable installations, see
Make sure that the delivery contains all necessary components.
Mount the units according to instructions in section Mounting the unit.
Procedure
1.
Strip the motor and mains cables. See
2. Open the front cover.

52 | Danfoss A/S © 2023.09
The length of the shielded cable
[m]
≤ 50
≤ 300
(1)
12.6 Cable Stripping
The distance between ca-
bles [ft]
1.0
3.3
Switching frequency
3.6 kHz
1.5 kHz
6.1.2 UL Standards on
Lengths.
AQ351737303996en-000201 / DPD00888
Electrical Installation
The length of the shielded cable
[ft]
≤ 164
≤ 984
Cabling.
